LEADING HYDRAULIC SYSTEMS SUPPLIER
Hidros, as the industry leader in hydraulic systems and components, offers high quality and reliable products. With our wide range of products, we provide the most suitable solutions for your industrial needs. We are at your service with our various products such as hydraulic pumps, Hydraulic mini power packs, hydraulic motors monoblock and sectional control valves, Hydraulic inline valves and more…
- As Hidros Group, we provide hydraulic solutions for agricultural, industrial, and mobile applications.
- We offer a variety of components used in numerous fluid power systems as complete sets.
- In response to market needs, we continue to develop new products in collaboration with distributors and OEMs, without compromising our principles of quality.
-
Directional Control Valves
P38 Series Monoblock Control Valves
Nominal flow rate: 35 liter/min
Max. Pressure: P: 250 bar, T: 50 bar, A-B: 300 bar
Spool type: Standard open center spool (A spool), different spool options
Number of spools: Single lever
Leakage: 5 cm3/min at 100 bar (From A,B to T)
Fluid temperature range: -10 oC … +80 oC
Working fluid: Mineral based hydraulic oil
Viscosity: 10-100 cSt (46 cSt mineral based hydraulic oil is recommended, may vary in different climates)
Filtration: 10 to NAS 1638SKU: n/a -
Hydraulic Motors & Brakes
VMF Series Hydraulic Motors
Max. displacement: Up to 801.8 cc/rev
Max. torque: 259 daNm (Cont. operation), 340 daNm (Intermittent operation)
Max. output power: 112 kW
Max. pressure drop: 250 bar (Cont. operation), 350 bar (Intermittent operation)
Max. oil flow: 240 liter/min
Min. speed: 5 rpmSKU: n/a -
HY100 Series, Hydraulic Oil Coolers
HY100 Series Oil Coolers with Gear Motor Driven Fan
- From 20 liter/min up to 190 liter/min flow rate
- Standard group 20 gear motor driven fan
- 72-75 dB noise level
- Anti-blockage turbulators
- Epoxy painted
- Radiator side is aluminum alloy
- With fixed thermostat (60/48 oC as standard)
- Interchangeable with most common brands
- working pressure is 24 bar
SKU: n/a -
Directional Control Valves
Z50 Series Solenoid Operated Directional Control Valves
Nominal flow rate: 50 liter/min
Max. Pressure: P: 315 bar, T: 50 bar, A-B: 300 bar
Spool type: Standard open center spool (A spool), different spool options
Number of spools: From 1 to 7
Leakage: Max. 18 cm3/min at 100 bar (From A,B to T)
Voltage: 12 V or 24 V DC
Fluid temperature range: -10 oC … +80 oC
Working fluid: Mineral based hydraulic oil
Viscosity: 10-100 cSt (46 cSt mineral based hydraulic oil is recommended, may vary in different climates)
Filtration: 10 to NAS 1638SKU: n/a
Click for PDF catalogue
-
Mini Power Packs Accessories
DC Motor Plastic Protection Covers
Plastic protection covers are assembled directly on DC motors of hydraulic mini power packs. They are suitable for 1.6/2.5 kW 12 V and 2.2 kW 24 V motors. They help to avoid contacting motor surface when the temperature is high and protect the motor from extenal impacts.
SKU: n/a
Hidros Group is a producer and supplier company of hydraulic products, founded in 1996, head office is located in Turkey and have branch offices in Bulgaria, Germany, South Africa. Our wide product range including hydraulic gear pumps, directional control valves, hydraulic valves, hydraulic motors and steering units, hydraulic mini power units, oil coolers, pump over gears, slewing drives, piston pumps, tractor and forklift replacement parts. Our products are exported over 60 countries…
